Project Diary: A Full System Install in Graystone Hills

Every job earns its own page in the diary. This one was a full conventional system for a four bedroom home in the Graystone Hills area of Conroe, replacing a system that had started surfacing in the back yard. Here is how the project actually unfolded, step by step.
The Perc Test Set the Plan
We started, as always, with a soil percolation test and a profile hole. The soil here drained slower than the owner expected, closer to a tight clay loam, which meant the drainfield needed more length than a sandy lot would. That single result shaped the entire design, and it is why we never quote a field before the soil tells us what it can handle. If you want the reasoning behind field sizing, our Drainfield Installation page walks through it.
Sizing the Tank and Pulling the Permit
Four bedrooms put this home in the 1,500 gallon tank bracket under the county sizing rules. We drew the system, submitted for the Montgomery County permit, and waited for approval before touching a shovel. Skipping the permit is how installers get systems dug up and redone, so we treat that approval as the real start date.
Excavation and Setting the Tank
With the permit in hand, the dig went quickly. We excavated the tank hole and the drainfield trenches in a single day, set the 1,500 gallon concrete tank dead level on a prepared base, and plumbed the Schedule 40 PVC inlet and outlet. The distribution box went in next, leveled carefully so every lateral would get an equal share of flow.
Laying the Field and Passing Inspection
We ran perforated pipe through the chamber trenches, wrapped in filter fabric to keep soil out of the system. Then came the part that matters most: the county inspector looked at the open tank, box, and trenches before a single scoop of backfill went back. It passed clean. We photographed everything, backfilled, and graded the yard to shed water away from the field.
The Result
The homeowner got a documented, permitted system and an as built drawing for their records. No more surfacing, no more worry at resale. That is the whole point of keeping this diary: the work is easier to trust when you can see how it went in.
Thinking about a new system or a failing field of your own? Contact us or call Mavia at (936) 307-9861 for a site evaluation in Conroe.
